Web-Manager Configuration
WiBox2100E User Guide 43
WEP Options
Authentication Select an authentication scheme (Open/None or Shared)
from the drop down menu.
Encryption Select the encryption type (64 bits or 128 bits for WEP) from
the pull-down menu. 64 bits is the default encryption for WEP.
Key Type Select the key type (Hex or Passphrase).
Key Enter the Encryption Key in hexadecimal value if Hex is
selected as the key type. Enter the key as a string if
Passphrase
is selected as the key type. Passphrase input is
not the same as ASCII input.
A passphrase of more than 20 characters is recommended.
Spaces and punctuation characters are permitted.
WPA Options
Authentication Select Pre-Shared Keys from the drop down menu.
Encryption Select the encryption type from the pull-down menu. TKIP is
the default encryption for WPA.
Key Type Select the key type (Hex or Passphrase).
Key Enter the Encryption Key in hexadecimal value if Hex is
selected as the key type. Enter the key as a string if
Passphrase
is selected as the key type. Passphrase input is
not the same as ASCII input.
A passphrase of more than 20 characters is recommended.
Spaces and punctuation characters are permitted.
Advanced Settings
Data Rate WiBox permits the control of the transmission data rate. Click
the Auto check box to allow the WiBox to automatically set
the data rate (or leave unchecked to set the transmission rate
manually). The default rate is 11 Mbps.
If the Auto check box is selected, choose the maximum data
rate from the drop down menu.
If the Auto check box is not selected, select the fixed data
rate (in Mbps) from the drop down menu.
Note:
Te maximum data rate cannot be selected when the
WiBox automatically sets the data rate. The WiBox supports
the following additional rates: 18 Mbps, 24 Mbps, 36 Mbps,
and 54 Mbps.
Radio Power
Management Power management reduces the overall power consumption
of the WiBox unit. Selecting Enable increases the response
time.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
