Introduction
WiBox2100E User Guide
16
Figure 2-7. RS-485 2-Wire Pinouts
WBX2100E Network Interface
The back panel of the WBX2100E contains a 9-30VDC power plug and an RJ45
(10/100) Ethernet port.
Figure 2-8. Network Interface
Power Plug
RJ45 Ethernet Port (WBX2100E only)
