Web-Manager Configuration
WiBox2100E User Guide 32
CPU Performance Mode Select the WiPort’s performance mode. Higher performance
settings require more energy. Low is 26 Mhz. Regular is 48
Mhz; High is 88 Mhz. The default is Regular.
HTTP Server Port This option allows the configuration of the web server port
number. The valid range is 1-65535. The default HTTP server
port number is 80.
MTU Size The Maximum Transmission Unit (MTU) is the largest physical
packet size a network can transmit for TCP and UDP. Enter
between 512 and 1400 bytes. The default setting is 1400
bytes.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Hostlist Configuration
The WiBox scrolls through the hostlist until it connects to a device listed in the hostlist
table. After a successful connection, the unit stops trying to connect to any others. If
this connection fails, the unit continues to scroll through the table in sequence until
the next successful connection.
The hostlist supports a minimum of 1 and a maximum of 12 entries. Each entry
contains an IP address and a port number.
Note: The hostlist is disabled for Manual and Modem Mode. The unit will not
accept a data connection from a remote device when the hostlist option is
enabled.
To configure the WiBox’s hostlist:
1. From the main menu, click the Hostlist tab.
Figure 4-4. Hostlist Settings
2. Enter or modify the following fields from the Hostlist Settings window:
