C-1 ACCESSORIES C-1
OPTIONAL ACCESSORIES
AND COMPATIBLE EQUIPMENT
Field Installed
K857 - Remote Output Control - For Stick welding.
Portable current control provides the same range as
the current control on the welder. Consists of a 6-pin
connector which plugs into the remote control connec-
tor. 25 foot cable length.
K870 - Foot Amptrol tm for TIG welding. The foot
Amptrol energizes the output and controls the output
remotely. The Foot Amptrol connects directly to the 6-
pin remote control connector.
K963-3 - Hand Amptrol tm for TIG welding. The hand
Amptrol energizes the output and controls the output
remotely. The Hand Amptrol connects directly to the
6-pin remote control connector.
K814 - Arc Start Switch - Energizes the output for
TIG welding if remote output control of the amperage
is not desired. It allows on/off TIG welding at the
amperage set by the Current Control on the control
panel. When using the Arc Start Switch set the Output
Control to the “LOCAL” position.
K2630-1 - Cool-Arc® 35 Water Cooler- Attaches
underneath the V310-T AC/DC and electrically con-
nects to the V310-T AC/DC. This smart cooler varies
its speed based on coolant temperature and monitors
coolant pressure.
K2694-1 Inverter Cart- Conveniently holds the Cool-
Arc 35 and V310-T AC/DC power source. Features a
tool storage tray for convenience and a cylinder plat-
form to hold a gas bottle
TIG TORCH STARTER KITS
K2266-1 – TIG-Mate 17 Air Cooled TIG Torch
Starter Pack. One complete easy-to-order kit pack-
aged in its own portable carrying case. Includes: PTA-
17 torch, parts kit, Harris flowmeter/regulator, 10 ft.
gas hose, Twist-Mate™ adapter, work clamp and
cable.
K2267-1 – TIG-Mate 20 Water-Cooled TIG Torch
Starter Pack. One complete easy-to-order kit pack-
aged in its own portable carrying case. Includes:
PTW-20 torch, parts kit, Harris flowmeter/regulator, 10
ft. gas hose, Twist-Mate™ adapter, work clamp and
cable, and 10 ft. water hose.
K2413-1- TIG-Mate 9 Air Cooled TIG Torch Starter
Pack. One complete easy-to-order Kit packaged in its
own portable carring case. Includes: PTA-9 Torch,
Gas Lens Parts Kit, Harris flowmeter/regulator, 10 Ft.
gas hose, Twist-Mate™ adapter, work clamp and
cable.
Magnum® TIG Torches – The following standard
Magnum® TIG torches may be used with the Invertec
V310-T AC/DC for Lincolnʼs full line of TIG torches
including flex head models consult publication
E12.150.
• K1781-1 PTA-9 12.5 ft.(3.8m) Air-Cooled 125A
• K1781-3 PTA-9 25 ft.(7.6m) Air-Cooled 125A
• K1782-1 PTA-17 12.5 ft.(3.8m) Air-Cooled 150A
• K1782-3 PTA-17 25 ft.(7.6m) Air-Cooled 150A
• K1783-1 PTA-26 12.5 ft.(3.8m) Air-Cooled 200A
• K1783-3 PTA-26 25 ft.(7.6m) Air-Cooled 200A
• K1784-3 PTW-20 12.5 ft.(3.8m) Water-Cooled 250A
• K1784-4 PTW-20 25 ft.(7.6m) Water-Cooled 250A
• K1784-1 PTW-18 12.5 ft.(3.8m) Water-Cooled 350A
• K1784-2 PTW-18 25 ft.(7.6m) Water-Cooled 350A
NOTE: Each torch requires a Twist-Mate™ adapter,
collets, collet bodies, and nozzles and are not includ-
ed and must be ordered separately.
V310-T AC/DC TIG
