Chapter4
Advanced Configuration
2
Wreless-G ADSL Home Gateway
Upstream Rate
The upload speed of traffic from the
Gateway to the Internet is displayed. For ADSL connection,
the Upstream Rate is typically 25% of the Downstream
Rate.
NOTE:
The Downstream and Upstream Rates are
affected by distance from and configuration of
the DSL central office.
Upstream Margn
The Upstream Margin is displayed.
Downstream Margn
The Downstream Margin is
displayed.
Downstream Lne Attenuaton
The Downstream Line
Attenuation is displayed.
Upstream Lne Attenuaton
The Upstream Line
Attenuation is displayed.
Downstream Transmt Power
The Downstream Transmit
Power is displayed.
Upstream Transmt Power
The Upstream Transmit
Power is displayed.
PVC Connection
Encapsulaton
The Encapsulation setting selected on
the Basic Setup screen is displayed.
Multplexng
The Multiplexing setting selected on the
Basic Setup screen is displayed.
QoS
The QoS method selected on the Basic Setup screen
is displayed.
PCR Rate
The PCR value entered on the Basic Setup screen
is displayed.
SCR Rate
The SCR value entered on the Basic Setup screen
is displayed.
Autodetect
The Autodetect setting selected on the Basic
Setup screen is displayed.
VPI
The VPI value entered on the Basic Setup screen is
displayed.
VCI
The VCI value entered on the Basic Setup screen is
displayed.
Enable
The number of Permanent Virtual Circuits (PVC)
is displayed.
PVC Status
The status of the PVC is displayed.
