Chapter4
Advanced Configuration
21 Wreless-G ADSL Home Gateway
QoS (Quality of Service)
QoS To use QoS, select Enable. Otherwise, keep the
default, Dsable.
Application-based QoS
Application-based QoS manages information as it is
transmitted and received. Depending on the settings of
the QoS screen, this feature will assign information a high,
medium, or low priority for the five preset applications
and three additional applications that you specify.
The five preset applications are the following:
FTP (File Transfer Protocol)
A protocol used to transfer files over a TCP/IP network
(Internet, UNIX, etc.). For example, after HTML pages
are developed for a website on a local machine, they
are typically uploaded to the web server using FTP.
HTTP (HyperText Transport Protocol)
The communications protocol used to connect to
servers on the World Wide Web. Its primary function
is to establish a connection with a web server and
transmit HTML pages to the client web browser.
Telnet
A terminal emulation protocol commonly used on
Internet and TCP/IP-based networks. It allows a user at
a terminal or computer to log onto a remote device
and run a program.
SMTP (Simple Mail Transfer Protocol)
The standard e-mail protocol on the Internet. It is a
TCP/IP protocol that defines the message format and
the message transfer agent (MTA), which stores and
forwards the mail.
POP3 (Post Office Protocol 3)
A standard mail server commonly used on the Internet.
It provides a message store that holds incoming e-mail
until users log on and download it. POP3 is a simple
system with little selectivity. All pending messages
and attachments are downloaded at the same time.
POP3 uses the SMTP messaging protocol.
Specfc Port# You can add three more applications by
entering their respective port numbers in these fields.
Hgh prorty/Medum prorty/Low prorty For each
application, select Hgh prorty (traffic on this queue
shares 70% of the total bandwidth), Medum prorty
(traffic on this queue shares 15% of the total bandwidth),
or Low prorty (traffic on this queue shares 10% of the
total bandwidth).
Click Save Settngs to apply your changes, or click Cancel
Changes to cancel your changes.
•
•
•
•
•
Administration > Management
This screen allows the network’s administrator to manage
specific Gateway functions for access and security.
Administration > Management
Gateway Access
Local Access
To ensure the Gateway’s security, you will be asked for your
User Name and password when you access the Gateway’s
web-based utility. The default User Name and password
are admn.
Gateway Username Enter the default Gateway
Username, admn.
Gateway Password Linksys recommends that you
change the default Gateway Password, admn, to one of
your choice.
Re-Enter to Confrm Enter the Gateway Password again
to confirm.
Remote Access
Remote Management To permit remote access to the
Gateway from outside the local network, select Enable.
Otherwise, keep the default, Dsable.
Management Port Enter the port number that will be
open to outside access.
Allowed IP Select All if you want to allow access from
any IP address. Select IP Addr. if you want to specify the IP
address that can access the Gateway. Then complete the
