1150 I/O card assembly
For access, remove these FRUs in order:
v
“1010 Digitizer pen” on page 85
v “1020 Battery pack” on page 86
v “1060 Keyboard” on page 97
v “1080 Palm rest” on page 101
v “1110 PCI Express Mini Card for wireless WAN” on page 110
v “1140 Keyboard bezel” on page 116
Table 23. Removal steps of I/O card assembly
1
2
4
3
5
Step Screw (quantity) Color Torque
5 M2 × 3.5 mm, wafer-head, nylon-coated (1) Silver 0.181 Nm
(1.85 kgfcm)
When installing: Make sure that the speaker connector is attached firmly.
Removing and replacing a FRU 119
