INITIAL SET-UP:
OPTIONAL IR MEDIA CONNECTOR
1. Turn off the second microphone.
The iR Media Connector uses
the same channel (channel B) as
the optional second microphone
(REDMIKE, LT-71, or REDMIKE
Share). As a result, they cannot be
used simultaneously. If you have
a second microphone, turn it off
before transmitting audio from the
iRMC.
NOTE: If you adjust the CH B
volume on the classroom audio
system, you will also be changing
the volume for your second
microphone. Return the CH B
volume knob to the original
position before turning the second
microphone back on.
2. The iR Media Connector volume
is preset for most standard audio
signals. If you need to turn the
volume up or down, follow this
procedure:
A. Adjust the volume at the
computer, television, or other
audio source if possible.
B. If the audio source does not
have a volume control (such
as many DVD players) adjust
the volume at the iRMC.
C. If the first two options do not
give optimum volume level,
the last place to adjust the
volume is the CH. B Volume
on the CAT 860.
860
REDMIKE Share: Initial Set-up
1. Ensure the CAT 860 is ON. The
RED LED on the power switch will
glow.
2. Turn on the REDMIKE Share by
sliding the switch to the top
position.
3. Grip the barrel in the center
section.
4. While speaking in a normal voice,
increase the B VOLUME level until
your voice is barely audible.
REMEMBER: This equipment
is designed to supplement
and distribute the user’s voice
so they are able to speak in a
conversational tone. Having the
volume set too high will result in
feedback and listener fatigue.
