14. RS-232 SERIAL INTERFACE
COMMAND DEFINITION
CONT’D
Symbol
Hex
Value
Value Definition
IICH p 0xB0 Command Packet:
The controller sends only
one character in
the command packet. The
possible values are shown
below:
0x80 = IR Channel A**
0x81 = IR Channel B
** Power up default
Response Packet:
The CAT 860 sends only
one character in
the response packet. The
possible values are shown
below:
0x80 = IR Channel A
0x81 = IR Channel B
This command determines
which volume-level EEPROM
variable will be affected
by the IIDI (<0xB2>), IIDD
(<0xB3>), and IIAV (<0xB4>)
commands.
If the command is properly
received, the CAT 860
responds by repeating back
the command packet where
the contains the
selection status
If the command is not
received properly, the CAT
860 responds by sending a
character.
Power up default is IR
Channel A selected.
QUERY SELECTED INFRARED INPUT COMMAND
IICH? 0xB1 Command Packet:
The controller sends no
character in the
command packet.
Response Packet:
The CAT 860 sends only
one character in
the response packet. The
possible values are shown
below:
0x80 = IR Channel A
0x81 = IR Channel B
This command causes the
CAT 860 to return a query
response packet where
the contains the
selection status set by IICH
(<0xB0>).
If the command is not
received properly, the CAT
860 responds by sending a
character.
ADVANCED COMMAND SET FOR AUDIO MIXER OPERATIONS CONT’D
Audio Input Functions for the Infrared Source Group
1. SELECT INFRARED INPUT COMMAND
Symbol
Hex
Value
Value Definition
AOAV? 0xA5 Command Packet:
The controller sends no
character in the
command packet.
Response Packet:
The CAT 860 sends two
characters in
the response packet. The
possible values are shown
below:
#1:
0x81 = AUX OUT
#2:
0xCF = 0 dB
0xCE = -1dB
0xCD = -2dB
0xCC = -3dB
0xA7 = -40dB
0x83 = -76dB
0x82 = -77dB
0x81 = -78B
0x80 = -79dB
This command causes the
CAT 860 to return a query
response packet where
the first of two
characters contains the
selection status set by
AOCH (<0xA0>) and the
second contains the value
stored in the volume-level
EEPROM variable selected
by the AOCH (<0xA0>)
command.
If the command is not
received properly, the CAT
860 responds by sending a
character.
14. RS-232 SERIAL INTERFACE
COMMAND DEFINITION
CONT’D
ADVANCED COMMAND SET FOR AUDIO MIXER OPERATIONS CONT’D
Audio Input Functions for the A/V Source Group Cont’d
9. QUERY ABSOLUTE VOLUME FOR SELECTED AUDIO OUTPUT COMMAND
