Symbol
Hex
Value
Value Definition
IMAI 0xE3 Command Packet:
The controller sends no
character in the
command packet.
Increment the volume for
microphone channel A
and B audio by 2 dB. This
overrides any previous mute
commands.
Response Packet:
If the command is properly
received, the CAT 860
responds by repeating
back the command packet
with an added imbedded
character
containing the value loaded.
If the command is not
received properly, the CAT
860 responds by sending a
character
DMAI 0xE4 Command Packet:
The controller sends no
character in the
command packet.
Decrement the volume of
the microphone channel A
and B audio by 2 dB. This
overrides any previous mute
commands.
Response Packet:
If the command is properly
received, the CAT 860
responds by repeating
back the command packet
with an added imbedded
character
containing the value loaded.
If the command is not
received properly, the CAT
860 responds by sending a
character.
14. RS-232 SERIAL INTERFACE
COMMAND DEFINITION
CONT’D
BASIC COMMAND SET FOR AUDIO SWITCHER OPERATIONS CONT’D
Audio Input Functions for the A/V Source Group Cont’d
4. INCREMENT MICROPHONE AUDIO INPUTS COMMAND
DECREMENT MICROPHONE AUDIO INPUTS COMMAND
14. RS-232 SERIAL INTERFACE
COMMAND DEFINITION
CONT’D
Symbol
Hex
Value
Value Definition
DAVS 0xE2 Command Packet:
The controller sends no
character in the
command packet.
Decrement the volume of
the selected audio input
by 2 dB. This overrides any
previous mute commands.
The remaining three
unselected audio/video
source inputs remain muted.
Response Packet:
If the command is properly
received, the CAT 860
responds by repeating
back the command packet
with an added imbedded
character
containing the value loaded.
If the command is not
received properly, the CAT
860 responds by sending a
character.
BASIC COMMAND SET FOR AUDIO SWITCHER OPERATIONS CONT’D
Audio Input Functions for the A/V Source Group Cont’d
3. DECREMENT AUDIO/VIDEO SOURCES COMMAND
