Linksys AG300 - Manual (Page 16)

10 Chapter 4: Connecting the ADSL Gateway
Connecting the Gateway to a Computer
ADSL Gateway
3. Connect one end of an Ethernet network cable to one of the Ethernet ports (labeled 1-4) on the back of the
Gateway, and the other end to an Ethernet port on a computer.
Repeat this step to connect more computers, a switch, or other network devices to the Gateway.
4. Connect the power adapter to the Gateway’s Power port, and then plug the power adapter into a power outlet.
The Power LED will immediately light up green. The Power LED will flash for a few seconds, and then it will be
solidly lit when the self-test is complete. If the LED flashes for one minute or longer, see “Appendix A:
Troubleshooting.”
5. Power on one of your computers that is connected to the Gateway.
Go to “Chapter 5: Configuring the ADSL Gateway.”
NOTE: You should always plug the Gateway’s power adapter into a power strip with
surge protection.
Figure 4-2: Connect a PC
Figure 4-3: Connect the Power
