6 Chapter 3: Getting to Know the ADSL Gateway
Ports and Reset Button on Side Panel
ADSL Gateway
Chapter 3: Getting to Know the ADSL Gateway
Ports and Reset Button on Side Panel
The Gateway’s ports and Reset button are located on a side panel.
Line The Line port connects to the ADSL line.
Ethernet (1-4) The Ethernet ports connect to your computers and other network devices.
Reset Button There are two ways to reset the Gateway's factory defaults. Either press the Reset Button, for
approximately ten seconds, or restore the defaults from the Factory Defaults screen of the
Administration tab in the Gateway’s Web-based Utility.
Power The Power port is where you will connect the power adapter.
IMPORTANT: Resetting the Gateway to factory
defaults will erase all of your settings
(including Internet connection and other
settings) and replace them with the factory
defaults. Do not reset the Gateway if you want
to retain these settings.
Figure 3-1: Ports and Reset Button on Side Panel
