The bottom panel – Linksys AG300 User Manual
Page 14
8
Chapter 3: Getting to Know the ADSL Gateway
The Bottom Panel
ADSL Gateway
The Bottom Panel
The Gateway has a built-in stand available. If you place the Gateway flat on a surface, then you can leave the
stand in the closed position. However, if you want the Gateway to be upright, swivel the stand clockwise 90º and
position the Gateway accordingly.
Figure 3-3: Bottom Panel with Stand in
Closed Position
Figure 3-4: Gateway Using Stand
