INSTALLATION
A-3
A-3
POWER WAVE 355/405
TECHNICAL SPECIFICATIONS -
POWER WAVE 405
INPUT AC VOLTAGE & DC OUTPUT
OUTPUT CABLES, CONNECTIONS AND LIMITATIONS
Product
Ordering
Input AC
Rated DC Output Output
Weight Dimensions
Name
Information Voltage
Amps/Volts/Duty Cycle
Range
with Cord
HxWxD
(continuous)
350A / 34V / 60%
14.7”x12.5”x
Power
200-208 /
3 Phase
27.8”*
Wave
K 2152-2 220-240/ 320A / 33V / 60%
AMPS
86.5lbs
(373x318x
405
380-415/
1 Phase
5-425
(37.4 kg) 706*)mm
3/50/60
60/50 Hz
275A / 31V /100%
1 Phase
300A / 32V / 100%
* Includes
3 Phase
handles
* Overall Length Including Handle, 21.6” (549mm) without handle.
Select the output cable size based upon the following chart.
Cable sizes for Combined Length of Electrode and Work Cable (Copper) 75C rated:
DUTY CYCLE
CURRENT
LENGTH UP 61m (200 FT)
61-76m (200-250 FT)
100%
275
1/0
1/0
60%
350
1/0
2/0
POWER WAVE 405 INPUT CURRENT
2. When operating on these inputs, the line cord should be changed to an input conductor of 6 AWG or larger.
1. Not rated is indicated by 4-x's in the box on the rating plate
Recommended Fuse Sizes Based On The U.S. National Electrical Code And Maximum Machine Outputs
Input 50/60 Hz
Output
Recommended
Voltage
Phases
300Amps@
350Amps@
Line Cord
Size Fuse Size Notes
32Volts(100%)
34Volts(60%) Size mm
2
200
3
41
48
16
80A
Note 2
220
3
37
48
16
80A
Note 2
380
3
23
28
10
50A
400
3
22
27
10
50A
415
3
22
26
10
50A
Voltage
Phases
275Amps@
320Amps@
Line Cord
Fuse Size Notes
31Volts(100%) 33Volts(60%)
Size mm
2
200
1
Not Recommended
Not Recommended
---
-----
Note 1
220
1
64
82
20
125A
Note 2
380
1
44
55
16
80A
Note 2
400
1
40
50
10
80A
415
1
38
48
10
80A
