6 Installation Considerations
Figure 2 System Control Cabinets
2.1 Types of System Control Cabinets
1. SCCT is a stand-alone cabinet containing system control logic for up to six UPS modules,
static bypass switch, manually operated disconnects for the static bypass switch, and two
motor-operated system breakers. The SCCT is painted the same color as the Liebert UPS, but
does not match the sheet metal style of the UPS.
2. SCCI has the system control logic, circuit breakers and static bypass switch integrated into a
switchboard cabinet manufactured by others.
3. SCCC is an integrated configuration like the SCCI with the static bypass switch rated for
continuous duty.
SCCT Dimensions
Amp WxD Weight
Ratings (Inches) (lbs.)
200-1200 37x37 1000
1600 62x48 1525
2000-2500 62x48 2850
3000 62x48 3100
4000 138x60 5850
