68
Type UFS 640si
Order no./color 20210138/silver
RF characteristics
Input frequency range MHz 950-2,150
Input level range dBµV 44-83
Reception threshold (EB/NO) dB < 4.5
TV system video
Modulation, FEC, de-multiplexer DVB-S standard
Video resolution CCIR 601 (720 x 576 lines), 576p, 720p, 1080i
Input data rate MSymb/s 2-45
S/N dB > 53
TV-System audio
Audio decoding MPEG-1 and MPEG-2, Layer 1 and 2
Sampling rate kHz 32/44.1/48
S/N dB > 65
Power supply
Supply voltage (external power supply) V
AC
/Hz 230/50 ± 10 %
DC voltage V 12
Power consumption (operation/stand-by mode) W < 26/< 2.5
LNB supply vert./horiz. V/mA 14/18/Max. 400
Control signal kHz 22; DiSEqC TM 1.0; SCR single-cable system
Connections
Sat-IF input/output (loop-through) 2 x F-type socket
TV/VCR output 2 x Scart socket
Video output Cinch socket
Video/audio output (digital) 1 x HDMI
Audio output (analogue) 2 x Cinch socket
Audio digital output (electrical) Cinch socket
Data interface RJ 11 socket
General
Perm. ambient temperature °C +5 to +40
Dimensions mm 255 x 47 x 190
Weight kg 1.0
TECHNICAL APPENDIX
