Here you can use the buttons to select the type of video signal at the TV Scart socket. Select
the signal that your TV set can process. When doing this, refer to the operating instructions for your
TV set!
• Composite baseband signal
(Colour Video Baseband Signal) or
• RGB - Red/Green/Blue signal
TV-SCART-OUTPUT
Here you can use the buttons to select the picture format for your TV. Either
4:3 or
16:9 format.
TV ASPECT RATIO
TV SETTINGS (TV, PICTURE AND SOUND)
Use the buttons here to select the type of screen display.
• Pan & Scan
• Letterbox
• Full-screen
PICTURE FORMAT
SETTINGS
Here you can use the buttons to specify whether your TV set is a
• PAL or
• NTSC set.
TELEVISION SYSTEM
Here you can use the buttons to set the picture format to be transmitted to your TV set via HDMI
Available options: “Auto” (automatic format choice), 576p, 720p or 1080i
HDMI FORMAT
