9. Bench Seat 13. Speakers
10. Bench Heater Panel 14. Reading Light
11. Back Rest 15. Temperature Sensor
12. Roof Vent
TOOLS REQUIRED
Screwdriver
Ladder
For easy installation, please distinguish each panel feature:
All side, front and back panels have
the molding toward the top.
FIGURE 4
3) Assembly Instructions
NOTE: Two adults are required for sauna assembly.
INSTALLATION ORDER
BOTTOM PANEL------ BACK PANEL ------ RIGHT PANEL ------ LEFT PANEL ------
BENCH HEATER PANEL------BENCH-----FRONT PANEL------BENCH-----TOP
PANEL-----TOP COVER
Choose a good location to install the sauna room
A. MAIN POWER cord must be easily accessible.
B. The location must be dry and leveled.
C. Far from any source of water
Caution: Assembly of sauna requires at least 2 adults to complete.
1) BOTTOM PANEL
Place the bottom panel on floor with the notches to the sides and closer to the rear of the sauna.
