Keys Fitness 2 Person Sauna BS-9202 - Manual (Page 14)

FIGURE 32
11) Seat the temperature sensor
After all the above connections are complete, go inside the room and remove the glue paper on the temp
sensor, then make it vertical with the TOP PANEL. (Figure 33)
FIGURE 33
12) Put on the TOP COVER
Lift the TOP COVER to the top of sauna room; feed the power cord and antenna (optional) through the round
holes on the TOP COVER, gently place the TOP COVER onto the rest of the TOP PANEL. When the four
edges are in the proper position, gently lower down and fasten them securely in place. (Figures 34 & 35)
FIGURE 34 FIGURE 35
SAUNA OPERATION
NOTE: Before powering on the sauna for the first time, please check and confirm the connection of
all wiring (CONTROL BOX, HEATERS, TEMPERATURE SENSOR etc.) are correct and
undamaged.
CONTROL PANEL FUNCTION
