Konica Minolta DiMAGE Scan Multi PRO - Manual (Page 61)

DiMAGE Scan Multi PRO
61
FOCUS
MANUAL FOCUS
Manual focus can be use with specific area of the image.
1. Click on .
• The pointer will change to the Manual Focus icon.
• Click on [Manual Focus] button again to escape the
function.
2. Click on the area of the image you wish to be in
sharp focus.
• The focus control window dialog box will appear.
3. Adjust the slider until the black and white lines
are at their longest for maximum
sharpness.
• Click and drag the slider to the left or right. Click
on the slider bar to make a larger change.
• To slightly defocus, adjust the sliders until the
black bar is a little shorter than the white bar.
4. Click on .
• A new prescan will begin.
• The prescanned image will appear in the
Prescan tab when complete.
