112
TECHNICAL APPENDIX
Type UFC 861si
Order no./ colour 20210116/Silver
RF range
Input frequency range MHz 2 x 47-862
Input level range dBµV 44-83
Demodulation dB QAM 16, 32, 64, 128, 256
TV system video
Modulation, FEC, demultiplexer DVB-C standard
Video resolution CCIR 601 (720 x 576 lines)
Audio decoding MPEG-1 and MPEG-2 compatible
Input data rate MSymb/s 1.7-7
Bit rate MBit/s 1.5-15
Frequency range MHz 0.02-5
Output voltage V
ss
1
S/N dB > 53
TV system audio
Audio decoding MPEG-1 and MPEG-2, Layer 1 and 2
Sampling rate kHz 32/44.1/48
Frequency range kHz 0.04-20
Output voltage mV
ss
770
S/N dB > 65
Memory
Flash-RAM/SDRAM MB 4/32
Processor clock speed MHz 166
Hard disk recorder
Capacity GByte 160
Recording time Std.
> 100 (depending on data rate and changes of
picture contents)
Power supply
Mains voltage V/Hz 100-240/50-60
Power consumption (operational mode/standby mode) W < 35/< 1
Connections
RF input/output 2 x IEC socket/pin
Connection TV/VCR 2 x Scart socket
Audio output (analogue/optical) 2 x Cinch socket/standard optical output
Data interface
Common Interface/ encoding system 1/Conax embedded
USB/Ethernet 1.1/1
General
Ambient temperature range °C Max. +5 to +40
Dimensions (W x H x D)/ Weight mm/kg 342 x 67 x 273/3.1
