Connection, English – Kenwood XR-1S User Manual
Page 8
8
English
P.CON
SPEAKER OUTPUT
REMOTE
FUSE [30Ax2]
GND
BATT.
LINE IN
LINE OUT
L
R
Connection
Remote cable (6.0 m : 19.7 ft)
Remote controller
■
Remote cable connection (Accessory of KAC-X1D, Optional accessory for XR-1S.)
CAUTION
• Before connecting the remote controller
cables, always turn the Bass boost level knob
all the way to the left.
