Español
P.CON
SPEAKER OUTPUT
REMOTE
FUSE [30Ax2]
GND
BATT.
LINE IN
LINE OUT
L
R
Conexiones
■
Conexión del cable del mando a distancia (Accesorio de KAC-X1D. Accesorio opcional
para XR-1S.)
PRECAUCIÓN
• Antes de conectar los cables del mando a
distancia, gire siempre el mando del nivel
de refuerzo de graves totalmente hacia la
izquierda.
Cable del mando a distancia
(6,0 m : 19,7 ft)
Mando a distancia
