Kawasaki Band Saw User Manual
Page 9
1. To adjust the height of the
upper blade guide loosen the
blade guide locking knob and
then adjust the height using
the blade guide adjustment
knob.
2. Tighten the blade guide locking
knob to secure the upper blade
guide in position.
A
AD
DJJU
US
ST
TIIN
NG
G T
TH
HE
E T
TH
HR
RU
US
ST
T B
BE
EA
AR
RIIN
NG
G
The thrust bearing must be adjusted after
every band saw blade change or tracking
adjustment.
1. Loosen the thrust bearing locking
screw with the Allen key supplied.
2. Adjust the bearing position until it is
1/32-inch away from the band saw
blade. When the band saw blade is
turned by hand, it should not contact
the thrust bearing.
3. Tighten the thrust bearing locking
screw.
1. Remove power to the band saw by turning the switch off and unplugging at the
power source.
2. To open the upper housing door, turn the upper housing locking screw to the
left and then (pull) the door open.
3. To open the lower housing door, turn the lower housing locking screw to the
left and then (pull) the door open.
A
AD
DJJU
US
ST
TIIN
NG
G T
TH
HE
E U
UP
PP
PE
ER
R B
BL
LA
AD
DE
E
The upper blade consists of a thrust bearing that supports the band saw blade from
the rear and two guide bearings that provide lateral adjustment. These guide bear-
ings need to be adjusted after every band saw change or any tracking adjustment.
The upper blade guide protects against unintentional contact with the saw blade.
For the upper blade guide to provide adequate protection against contact with the
band saw blade, it must always be set as close as possible against the work piece
(maximum distance 1/8 inch).
A
Allw
waayyss een
nssu
urree tth
haatt tth
hee ssaaw
w iiss ssw
wiittcch
heed
d o
offff aan
nd
d
u
un
np
pllu
ug
gg
geed
d ffrro
om
m tth
hee p
po
ow
weerr ssu
up
pp
pllyy b
beeffo
orree m
maakkiin
ng
g aan
nyy aad
djju
ussttm
meen
nttss.. FFaaiillu
urree tto
o
d
do
o sso
o ccaan
n ccaau
ussee eelleeccttrriiccaall ssh
ho
occkk,, iin
njju
urryy o
orr d
deeaatth
h..
15
16
CLOSE
OPEN
1/32" FROM BLADE
1/8"
