12

EN

COAXIAL

OPTICAL

OPTICAL

VIDEO 3

CD/DVD

DIGITAL IN

DVD/

6CH

VIDEO

2

Digital connections

The digital in jacks can accept DTS, Dolby Digital, or PCM signals. Connect components capable of outputting DTS, Dolby Digital, or standard PCM (CD)
format digital signals.
If you have connected any digital components to the receiver, be sure to read the “Input mode settings” section carefully.

8

COAXIAL

DIGITAL

OUT

(AUDIO)

Connect the video signal and digital
audio signals to the VIDEO 3 jacks.
(See “Connecting video compo-
nents”.)

!

DOLBY DIGITAL RF
OUT (AUDIO)

OPTICAL DIGITAL OUT (AUDIO)

LD Player

PCM OUT

Component with DTS,
Dolby Digital, or PCM
OPTICAL DIGITAL OUT

Setting up the system

RF digital demodulator
(Commercially avail-
able)

CD Player or DVD Player

OPTICAL DIGITAL OUT (AUDIO)

Optical fiber cable

Component with DTS,
Dolby Digital, or PCM
COAXIAL DIGITAL OUT

Optical
fiber cable

COAXIAL DIGITAL OUT (AUDIO)

To connect an LD player with a DIGITAL RF OUT, connect the LD player to the RF digital demodulator (Commercially available).
Next, connect the DIGITAL OUT jacks of the demodulator to the DIGITAL IN jacks of the receiver.
Connect the video signal and analog audio signals to the VIDEO 2 or VIDEO 3 jacks. (See “Connecting video components”.)

Connect the video signal and analog
audio signals to the VIDEO 2 jacks.
(See “Connecting video compo-
nents”.)

!
