35 EN
Specifications Caution : Read this page carefully to ensure safe
operation.
For the U.S.A and Canada
AUDIO section (VR-605/615)
Rated power output during STEREO operation
Effective power output during SURROUND operation
FRONT (40 ~ 20 kHz, 0.7% T.H.D. at 8 Ω one channel driven)
............................................................................... 100 W + 100 W
CENTER (40 ~ 20 kHz, 0.7% T.H.D. at 8 Ω one channel driven)
.............................................................................................. 100 W
SURROUND (40 ~ 20 kHz, 0.7% T.H.D. at 8 Ω one channel
driven) ................................................................... 100 W + 100 W
SUBWOOFER (80 Hz, 0.7% T.H.D. at 8
Ω one channel driven)
(VR-615) ................................................................................ 100 W
Total harmonic distortion ........................... 0.05% (1 kHz, 50 W, 8 Ω)
Frequency response
CD ............................................... 20 Hz ~ 70 kHz, +0 dB, –3.0 dB
Signal to noise ratio (IHF’66)
CD .......................................................................................... 95 dB
Input sensitivity / impedance
CD ......................................................................... 550 mV / 47 k Ω
DVD/6CH INPUT (VR-615) .................................. 550 mV / 47 k Ω
Output level / impedance
TAPE REC ............................................................... 550 mV / 1 k Ω
PRE OUT (SUBWOOFER) (VR-605) ...................... 1.5 V / 2.2 k Ω
Tone control
BASS ................................................................ ±10 dB (at 100 Hz)
TREBLE ............................................................ ±10 dB (at 10 kHz)
Loudness control
VOLUME at -30dB level ................................... +8 dB (at 100 Hz)
For other countries
AUDIO section (KRF-V5060D/V5560D)
Rated power output during STEREO operation
Effective power output during SURROUND operation
FRONT (1 kHz, 0.7% T.H.D. at 8 Ω one channel driven)
............................................................................... 100 W + 100 W
CENTER (1 kHz, 0.7% T.H.D. at 8 Ω one channel driven)
.............................................................................................. 100 W
SURROUND (1 kHz, 0.7% T.H.D. at 8 Ω one channel driven)
............................................................................... 100 W + 100 W
SUBWOOFER (80 Hz, 0.7% T.H.D. at 8 Ω one channel driven)
(KRF-V5560D) ...................................................................... 100 W
Total harmonic distortion ........................... 0.05% (1 kHz, 50 W, 8 Ω)
Frequency response
CD ............................................... 20 Hz ~ 70 kHz, +0 dB, –3.0 dB
Signal to noise ratio (IHF’66)
CD, TUNER, AUX, TAPE ...................................................... 95 dB
Input sensitivity / impedance
CD ......................................................................... 550 mV / 47 k Ω
DVD/6CH INPUT (KRF-V5060D) ........................ 550 mV / 10 k Ω
Output level / impedance
TAPE REC ............................................................... 550 mV / 1 k Ω
PRE OUT (SUBWOOFER) (KRF-V5060D) ............. 1.5 V / 2.2 k Ω
Tone control
BASS ................................................................ ±10 dB (at 100 Hz)
TREBLE ............................................................ ±10 dB (at 10 kHz)
Loudness control
VOLUME at -30dB level ................................... +8 dB (at 100 Hz)
AUDIO section (KRF-V4060D)
Effective power output during STEREO operation
1 kHz, 0.7% T.H.D.,at 8 Ω ............................................. 50 W + 50 W
Rated power output during STEREO operation
Effective power output during SURROUND operation
FRONT (1 kHz, 0.7% T.H.D. at 8 Ω one channel driven)
................................................................................... 50 W + 50 W
CENTER (1 kHz, 0.7% T.H.D. at 8 Ω one channel driven)
................................................................................................ 50 W
SURROUND (1 kHz, 0.7% T.H.D. at 8 Ω one channel driven)
................................................................................... 50 W + 50 W
Total harmonic distortion ........................... 0.15% (1 kHz, 20 W, 8 Ω)
Frequency response
CD ............................................... 20 Hz ~ 70 kHz, +0 dB, –3.0 dB
Signal to noise ratio (IHF’66)
CD, TUNER, AUX, TAPE ...................................................... 95 dB
Input sensitivity / impedance
CD ......................................................................... 400 mV / 47 k Ω
Output level / impedance
TAPE REC ............................................................... 400 mV / 1 k Ω
PRE OUT (SUBWOOFER) ...................................... 1.5 V / 2.2 k Ω
Tone control
BASS .................................................................. ±10 dB (at 70 Hz)
TREBLE ............................................................ ±10 dB (at 10 kHz)
Loudness control
VOLUME at -30dB level ................................... +8 dB (at 100 Hz)
DIGITAL AUDIO section
Sampling frequency ...................... 32 kHz, 44.1 kHz, 48 kHz, 96 kHz
Input level / impedance / wave length
Optical ........................... (–15 dBm ~ –21 dBm), 660 nm ±30 nm
Coaxial ................................................................... 0.5 Vp-p / 75
Ω
VIDEO section
VIDEO inputs / outputs
VIDEO (composite) ................................................. 1 Vp-p / 75 Ω
FM tuner section
Tuning frequency range ................................. 87.5 MHz ~ 108.0 MHz
Usable sensitivity (MONO)
VR-605/615
................. 1.3 µV (75 Ω)/ 13.2 dBf (75 kHz DEV., SINAD 30 dB)
KRF-V5060D/V4060D/V5560D
................... 1.6 µV (75 Ω)/ 15.2 dBf (75 kHz DEV., SINAD 30 dB)
50dB quieting sensitivity
STEREO ..................................................... 28 µV (75 Ω)/ 40.2 dBf
Total harmonic distortion (1 kHz)
MONO .......................................................... 0.5% (71.2 dBf input)
STEREO ....................................................... 0.7% (71.2 dBf input)
Signal to noise ratio (1 kHz, 75 kHz DEV.)
MONO ........................................................ 75 dB (71.2 dBf input)
STEREO ..................................................... 68 dB (71.2 dBf input)
Stereo separation (1 kHz) ........................................................... 40 dB
Selectivity (±400 kHz) VR-605/615 ............................................ 70 dB
KRF-V5060D/V4060D/V5560D ............. 50 dB
Frequency response .................... (30 Hz ~ 15kHz), +0.5 dB, –3.0 dB
AM tuner section
Tuning frequency range
10 kHz step (VR-605/615) ........................... 530 kHz ~ 1,700 kHz
10 kHz step (KRF-V5060D/V4060D/V5560D) ..............................
...................................................................... 530 kHz ~ 1,610 kHz
9 kHz step (KRF-V5060D/V4060D/V5560D) ................................
...................................................................... 531 kHz ~ 1,602 kHz
Usable sensitivity (30% mod., S/N 20dB) (VR-606/615)
........................................................................ 16 µV / (600 µV/m)
Usable sensitivity (KRF-V5060D/V5560D/V4060D) ...........................
........................................................................ 16 µV / (600 µV/m)
Signal to noise ratio (30% mod. 1 mV input) ........................... 50 dB
GENERAL
Power consumption VR-605/615 ................................................ 2.2 A
KRF-V5060D/V5560D .............................. 280W
KRF-V4060D ............................................. 200W
AC outlet
SWITCHED
VR-605/615 ........................................ (total 150 W, 1.25 A max.)
KRF-V5060D/V4060D/V5560D ....................... (total 90 W max.)
Dimensions .................................................... W : . 440 mm (17-5/16")
H : 143 mm (5-5/8")
D : 303 mm (11-15/16")
Weight (Net)
VR-605/615 ......................................................... 7.7 kg (17.00 lb)
KRF-V5060D/V5560D ......................................... 8.8 kg (19.40 lb)
KRF-V4060D ........................................................ 7.9 kg (17.41 lb)
100 watts per channel minimum RMS, both channels driven, at 8 Ω from
40 Hz to 20 kHz with no more than 0.7% total harmonic distortion. (FTC)
100 watts per channel minimum RMS, both channels driven, at 8 Ω from
40 Hz to 20 kHz with no more than 0.7% total harmonic distortion. (FTC)
40 watts per channel minimum RMS, both channels driven, at 8 Ω from
40 Hz to 20 kHz with no more than 0.7% total harmonic distortion. (FTC)
