10 EN
VIDEO 2
COAXIAL
DVD
DIGITAL IN
CD / DVD
OPTICAL
VOLTAGE
SELECTOR
AC110V-120V / 220V-240V~
50 / 60Hz SWITCHED TOTAL 90W MAX.
AC OUTLETS
AC 220-
240V~
AC 110-
120V~
SPEAKERS
SURROUND
SPEAKERS
(8-16 Ω)
CENTER SPEAKER (8-16 Ω)
FRONT SPEAKERS (8-16 Ω)
GRAY WHITE GREEN BLUE RED
L C R L R
CENTER
SUB WOOFER PRE OUT
SUB WOOFER SURROUND FRONT
DVD / 6CH INPUT
PLAY IN
VIDEO 2 DVD
AUDIO
REC OUT PLAY IN VIDEO1 PHONO REC OUT PLAY IN MD / TAPE CD / DVD
L
R
GND
VIDEO 1 OUT VIDEO 1 IN
VIDEO
VIDEO 2
IN
DVD
IN
MONITOR
OUT
ANTENNA
GND
AM FM 75 Ω 75 µs AM 10kHz
FM 100kHz 50 µs AM 9kHz
FM 50kHz
DE-
EMPHASIS
CHANNEL
SPACE SYSTEM
CONTROL
+
-
+
-
AUDIO
PLAY IN
VIDEO 2 DVD REC OUT PLAY IN
VIDEO1 VIDEO 1
OUT
VIDEO 1
IN
VIDEO
VIDEO 2
IN
DVD
IN
MONITOR
OUT
Setting up the system
Connecting video components
Video inputs and
outputs
(Yellow RCA pin cords) Audio inputs
and outputs
OUT OUT
Monitor TV
Video inputs
(Yellow RCA pin cords)
VIDEO
IN
A video component with digital audio outputs should be connected to the VIDEO2 jacks.
Video deck
IN IN
OUT OUT
OUT OUT
Video
IN/OUT
Audio
IN/OUT
DVD player or LD player
DVD player or LD player
For VR-605/
KRF-V4060D/
V5560D only
