4
ZX AMPLIFIERS
AMP1
AMP1
L+ L-
R+ R-
AMP2
L+ L-
R+ R-
L+ BRIDGE WIRING R-
AMP2
L
L
R
R
L+ L- R+ R-
L+ L- R+ R-
REMOTE BASS
AUTO
TURN ON
+12V DC AUDIO
OFFSET
LO
HI
INPUT
SPKR +
SPKR -
INPUT
SENSITIVITY
L
XOVER
OFF HI LO
OUTPUT
L
R
R
SPKR +
SPKR -
BRIDGED OPERATION (MONO)
minimum impedance of 4 ohms
ZXRC* REMOTE BASS
INSTALLATION
signal in
AMP1
AMP1
L+ L-
R+ R-
AMP2
L+ L-
R+ R-
L+ BRIDGE WIRING R-
AMP2
L
L
R
R
L+ L- R+ R-
L+ L- R+ R-
1. mount the
metal bracket
* ZXRC not included
4-conductor phone cable
back view
2. slide the housing until it snaps
into the metal bracket
STEREO-AND-MONO-SIMULTANEOUSLY (SAMS) OPERATION
minimum impedance of 4 ohms bridged (mono) and 2 ohms per channel stereo
signal in
woofer
woofer
woofer
