Page 9

GB/IE

1 x Stripping tongs or cable stripping knife
1 x Screwdriver
1 x SW 8 spanner (jaw size 8 mm)
1 x Ballpoint pen

For the connection of an aerial installed in the
vehicle you may require :
1 x Aerial adapters (in accordance with the technical

data of the aerial)

For the connection of an amplifier you will
require:
2 x Cinch connection cables

(insulation and plug: white / red)

Installation

Removing the control panel from

the car radio

• Avoid hard contact with the display window

• Press the “Open” button

and allow the control

panel

to reach the horizontal position.

• Push the control panel

slightly to the left

and pull it forwards.

• Store the control panel in the plastic box (see

also the illustration in the section „Attaching
the Control Panel“).

Installing the DIN assembly bracket

in the vehicle‘s instrument panel

• Remove all packing material from the device.
• Unscrew the safety transport screws

com-

pletely from the metal housing

(see Fig. E)

and carefully release the plastic frame

from

the front of the device

• Release the attachment points by slightly raising

the upper frame edge and pulling it carefully
towards the front.

• Push the two installation keys

between the

metal housing

and the preassembled DIN as-

sembly bracket

until they clearly lock in place.

Ensure that the convex side faces outwards in

each case. Store the installation keys

carefully

for future use.

• Remove the DIN assembly bracket

and place

it flush in the DIN assembly cut-out of the vehi-
cle‘s instrument panel.

• Secure the DIN assembly bracket

against

removal. Bend approximately ten tin dog points
on both the upper and lower side of the DIN
assembly bracket

from the inside towards the

outside. Please ensure that the DIN assembly
bracket

is installed flush in the DIN assembly

cut-out.

• Attached the plastic frame

completely to the

front of the device

Connecting to the loudspeakers

of the vehicle

Tip! Use an ISO plug.

• Guide the connection cables of the loudspeakers

mounted in the vehicle carefully out of the front
of the DIN assembly bracket

• Establish the connection between the connection

cables of the ISO plug and the connection cables
of the loudspeakers fitted to the vehicle with
the help of biscuit connectors, ensuring that
the connections in the biscuit connectors do
not cause any short circuits and that the fixing
screws are firmly tightened.
