• Then insert the second red plug of the second
cinch connection cable as far as it will go into
the FRONT cinch plug jack (amplifier connection
[red / front right]) of the amplifier.
• Insert the white plug of the second cinch
connection cable as far as it will go into the
OUT / FRONT cinch plug jack (amplifier connec-
tion [white / front left])
gn .
• Then insert the second white plug of the second
cinch connection cable as far as it will go into
the FRONT cinch plug jack (amplifier connection
[white / front left]) of the amplifier.
L Connecting a portable audio device
For establishing a cinch connection to any audio
source the headphone output (3. mm stereo jack)
of any audio device (e.g. MP3 player) can be con-
nected to the car radio.
Use a 3. mm jack plug connection cable to 2 x
cinch plugs.
• Guide the cinch connection cable to the portable
audio device and carefully out of the front of the
DIN assembly bracket.
• Insert the red plug of the cinch connection cable
as far as it will go into the LINE IN R cinch plug
jack [red / rear right]
ft .
• Insert the white plug of the cinch connection
cable as far as it will go into the LINE IN L cinch
plug jack [white / rear left]
fu .
• Then insert the 3. mm stereo jack into the
headphone output of the audio device.
• In order to play back the sound, press the
• MODE button cn , until the letters AUX appear
in the display window.
For operation of the external device, please see
its operating instructions.
L Connecting to the aerial
of the motor vehicle
• Guide the connection cable of the vehicle aerial
carefully out of the front of the DIN assembly
bracket
iq up to the car radio.
• Insert the plug of the connection cable of the
vehicle aerial as far as it will go into the aerial
socket
gm of the car radio. If necessary, use an
aerial adapter in accordance with the technical
data of the aerial.
• If present: Connect the 12 V DC connection cable
of an electric aerial to the electric aerial fo
plug-in.
L Attaching to the
DIN assembly bracket
• Insert the rear of the car radio together with the
connected cables carefully into the DIN assembly
bracket
iq .
• Ensure that no objects are able to cover the
vents of the metal housing du .
• Ensure that there is no connection cable between
the metal housing du and the DIN assembly
bracket iq .
Prevent the cables from becoming caught, as
any damage may result in a short circuit and
malfunctioning of the device or the vehicle‘s
electronic system.
• Push the car radio into the DIN assembly
bracket iq until it distinctly locks in place.
• You should also secure your device against theft.
Fix the attachment screw fr with the anchoring
plate and the attachment material to the engine
fire wall of the vehicle.
• Fix the attachment screw fr with the M nut and
washer to the holder of the assembly cut-out of
the vehicle.
• Ensure that all cables are properly connected
and that the power supply is working correctly.
The LED (red) / power supply
dq flashes.
• Use the tip of a ballpoint pen to press the reset
button dr on the front of the device (see Fig. C).
The default settings are activated.
L Attaching the control panel
• Remove the control panel 1 from the plastic
box.
• Avoid hard contact with the display window 9 .
