Page 5
7
GB/IE
et
Plug-in for rear left loudspeaker (-)
eu
Flat blade fuse socket
f
l
Flat blade fuse 10 A
fm
ISO plug jack to the 12 V DC power connection
(including connection of an automatic aerial)
fn
Plug-in for 12 V DC constant current
fo
Plug-in for electric aerial
fp
Plug-in for 12 V DC ignition current
fq
Plug-in for minus / earth connection in the vehicle
fr
Attachment screw (including M nut and washer)
fs
OUT / REAR cinch R plug jack (loudspeaker
connection [red / rear right])
ft
LINE IN R cinch plug jack (red / right)
fu
LINE IN L cinch plug jack (white / left)
gl
OUT / REAR cinch L plug jack (loudspeaker
connection [white / rear left])
gm
Aerial socket
gn
OUT / FRONT cinch plug jack (loudspeaker
connection [white / front left])
go
OUT / FRONT cinch plug jack (loudspeaker
connection [red / front right])
Top of the Car Radio (see Fig. E)
gp
Transport safety screw 2 x
Front of the Remote Control (see Fig. F)
gq
POWER
“POWER” button
gr
ENTER
SEL
“ENTER / SEL” button
gs
TUNE/
SEEK
VOL
VOL
9
:
“TUNE / SEEK” multifunction button:
gt
VOL
“VOL+” button (upper)
gu
9
Skip button (back)
hl
:
Skip button (forwards)
hm
VOL
“VOL” button (lower)
hn
MODE
“MODE” button
ho
MP3
AS/PS
“MP3 / AS / PS” button
hp
-10
5
“-10 / ” button
hq
+10
6
“+10 / 6” button
hr
DISP
“DISP” button
hr
BAND
“BAND” button
ht
RDM
4
“RDM / 4” button
hu
RPT
3
“RPT / 3” button
il
INT
2
“INT / 2” button
im
PAU
1
“PAU / 1” button
Rear of the Remote Control (see Fig. G)
in
Battery compartment
io
Battery holder
ip
Unlock button
Installation Accessories (see Fig. E)
iq
DIN assembly bracket
ir
Installation key
L
Scope of Supply
1 x Car radio (including control panel)
1 x IR remote control (including 1 x lithium battery
of type CR202, 3 V DC)
1 x Plastic box (for control panel)
1 x DIN assembly bracket
2 x Installation key
1 x Anchoring plate (including attachment material)
1 x Operation manual
L
Technical Data
Car Radio
Rated voltage: 12 V DC (minus pole negative,
connected to the body within the vehicle)
Power consumption: max. 10 A
Power output: max. 4 x 20 W active power factor
Distortion: - 40 dB (1%)
Amplifier (TDA 7386)
4-band preset EQ
Electronic master level for: bass and treble, loudness,
fade control, balance
Preamplifier Input (LINE IN)
Power output: 77 m V = 0 dB
Impedance: 47 k Ohm
Preamplifier Output (LINE OUT)
Power output: max. V
Impedance: 10 k Ohm
Tone control
Bass frequency: 100 Hz ± 10 dB
Treble frequency: 10 kHz ± 10 dB
Introduction
