21 GB/IE
Disconnection
• Remove the USB plug of the USB audio storage
medium completely from the USB port do .
Or
• Press the SD / MMC in the SD and MMC port
dn
in order to unlock it.
• Remove the SD / MMC from the SD and MMC
port dn .
L Remote Control
Tip!
Familiarise yourself with use of the similar buttons
on the remote control (see Fig. F). Please see the
layout of the control panel
1 for the functions.
Ensure that the front edge of the remote control is
pointing in the direction of the sensor
3 of the re-
mote control 1 .
• Please note that the AF function only works with
ther
AF
button 8 on the control panel 1 .
• Please also note the modified procedure for:
Adjusting the Volume
• Increase the volume by pressing the
VOL+ button
gt .
• Reduce the volume by pressing the
VOL- button hm .
Inserting the Battery
• Press the unlock button
ip and remove the
battery holder io from the battery compart-
ment in (see Fig. G).
• Insert a lithium battery of type CR202, 3 V DC
into the battery holder io in such a way that
the side marked with a “+” is facing upwards.
Then push the battery holder
io into the battery
compartment in until it distinctly locks into place.
L Troubleshooting
E Fault e Cause E Correction
E The device cannot be switched on and / or
[ERROR] appears in the display window 9 .
The connections of the 12 V DC power supply
are faulty.
E Check that the wiring of the device is correct
(see the section on „Connecting to the Vehicle‘s
12 V DC Power Supply“). Then press the RESET
button
dr with the tip of the ballpoint pen.
Or
The 10 A f l flat blade fuse in the flat blade
fuse socket eu is broken.
E Replace the broken flat blade fuse with a new
10 A flat blade fuse. Then press the RESET
button
dr with the tip of the ballpoint pen.
Or
A 1 A fuse of the fuse holder of the 12 V DC
power supply is broken.
E Replace the broken fuse with a new 1 A fuse.
Then press the RESET button dr with the tip of
the ballpoint pen. If the fuse is broken again,
check that the wiring is correct.
Or
The device is broken.
E Please contact the service centre for your
country (see guarantee card).
E The device cannot be operated.
The control panel 1 is wrongly connected.
E Ensure that the control panel 1 is correctly
connected (see the section on attaching the
control panel).
Or
The battery of the remote control is flat.
E Replace the used battery with a new lithium
battery of type CR202, 3 V DC.
Or
The sensors 3 of the control panel 1 and / or
remote control may be dirty.
E Clean the sensor 3 of the control panel 1 or
the remote control if necessary.
Or
The device is broken.
E Please contact the service centre for your
country (see guarantee card).
E The stored stations do not remain stored if
the control panel is removed or the engine
turned off.
The connections for 12 V constant current fn and
12 volt ignition current fp have been mixed up
Operation / Remote Control / Troubleshooting
