15 EN
+ + - -
FRONT B
R L
SUB
WOOFER
CENTER
GRAY
SURROUND
R L
-
+
BLUE
PURPLE
SURROUND BACK/
SUBWOOFER
GREEN WHITE RED
R L CENTER FRONT A
-
+
Connecting the speakers
Setting up the system
Right
Front Speakers A
Right
Left
Center
Speaker
Surround Speakers
(Be sure to connect both
surround speakers)
Left
Surround Back/Subwoofer
Use this terminal it you wish to
connect to a Surround Back
speaker with the SETUP of
“6ch AMP SB” or to connect
to a Subwoofer speaker with
the SETUP of “6ch AMP SW”.
Front Speakers B
Right Left
Powered
subwoofer
