KTM 450 SMR 2008 - Manual (Page 20)

450 SMR 2008
FIG PART NUMBER DESCRIPTION QTY
1 7731020104430 REAR WHEEL CPL. 5X17 SMR 08 1
2 78010010044 REAR HUB CPL. 08 1
3 59010011000 BUSHING SPACER TUBE 121,5MM 01 1
4 0625060058 GR.BALL BEAR.6005 DDU2CG23S6NM 2
5 0472047175 CIRCLIP DIN0472-47X1,75 1
6 0760324771 SHAFT SEAL RING 32X47X7 BSL 2
7 78010016000 BUSHING FOR HUB 08 2
8 58309071100 SPOKE M5X174-13,5G 17" 36
9 58309072000 SPOKE NIPPLE M5-TA (8X21MM) 36
10 59410070000 RIM 5X17" SMR 07 1
11 77310060000 BRAKE DISC REAR 220 1
12 59009062013 SPECIAL SCREW M6X13 WS=8 10.9 6
13 58309073000 RIM BAND 17" 1
15 78010015000 REAR WHEEL REP. KIT x
19 58310051038 REAR SPROCKET 38-T x
19 58310051042 REAR SPROCKET 42-T x
19 58310151040 REAR SPROCKET 40-T x
19 58310151045 REAR SPROCKET 45-T x
19 58310151048 REAR SPROCKET 48-T x
19 58310151049 REAR SPROCKET 49-T x
19 58310151050 REAR SPROCKET 50-T x
19 58310151051 REAR SPROCKET 51-T x
19 58310151052 REAR SPROCKET 52-T x
21 0019080266S COUNTER-SUNK SCREW ISA45 M8X26 6
22 54310086200 SELF LOCKING NUT M8 10.9 6
23 50310165118 CHAIN 5/8X1/4" MX 1
23 50310800118 CHAIN Z-RING 5/8X1/4" 1
24 50310166000 CONNECTING LINK F. 50310165118 1
24 50310366000 CONNECTING LINK F. 50310800118 1
24 50310866000 MASTER LINK FOR 50310800118 1
40 77310085044 WHEEL SPINDLE RE. CPL.265MM 07 1
41 50310084000 CHAIN TENSIONER R/S 2000 1
42 50304040100 SCREW M10X1,25X50 WS=10 2
43 58414030000 HH COLLAR NUT M10X1,25 WS=13 2
44 50310099000 HEXAGON NUT M20X1,5 '98 1
087731010 / C087731011 * NEW PART X AS REQUIRED
18
REAR WHEEL
