Other Information
76
Chapter 7: Other Information
Video Section
Video output format ........................................ PAL/PAL60*/NTSC*
...................................................... ( * NTSC disc play only)
Composite video output level ................................... 1 Vp-p (75 Ω )
S-video output level
(Y-signal) .............................................................. 1 Vp-p (75 Ω )
(C-signal) ...................................................... 0.286 Vp-p (75 Ω )
Component video output level
[For Europe and U.K.]
(Y-signal) .............................................................. 1 Vp-p (75 Ω )
(C B -signal) ......................................................... 0.7 Vp-p (75 Ω )
(C R -signal) ......................................................... 0.7 Vp-p (75 Ω )
Component video output level
(Interlace/”Black Level Setup”=7.5 IRE)
[Except for Europe and U.K.]
(Y-signal) .............................................................. 1 Vp-p (75 Ω )
(C B -signal) ....................................................... 0.68 Vp-p (75 Ω )
(C R -signal) ....................................................... 0.68 Vp-p (75 Ω )
RGB output level (SCART) ...................................... 0.7 Vp-p (75 Ω)
Video signal to noise ratio ....................................................... 65 dB
Horizontal resolution ......................................................... 500 lines
Format section
Format ............................. DVD audio ver. 1.2 / DVD video ver.1.1
Laser ............................................................. Semiconductor laser
Audio section
Frequency response
Sampling frequency: 44.1kHz (CD only) ........... 4 Hz~20 kHz
Sampling frequency: 48 kHz ............................... 4 Hz~22 kHz
Sampling frequency: 96 kHz ............................... 4 Hz~44 kHz
Sampling frequency: 192 kHz (DVD AUDIO only)
........................................................................ 4 Hz~88 kHz
Signal to noise ratio ............................................. More than 120 dB
Dynamic range ..................................................... More than 100 dB
Total harmonic distortion ..................... Less than 0.003 % (1kHz)
Channel separation .................................. More than 95 dB (1kHz)
Analog output level/impedance
MIX LINE OUTPUT ................................................... 2 V/ 510 Ω
6 CH. OUTPUT ........................................................ 2 V / 510 Ω
Digital output level/impedance
COAXIAL ............................................................ 0.5 Vp-p/ 75 Ω
OPTICAL (Wave length 660 nm) ............... -21 dBm ~ -15 dBm
Headphone output ........... 30 mW/ 32 Ω load (Phones level MAX)
KENWOOD follows a policy of continuous
advancements in development. For this reason
specifications may be changed without notice.
Sufficient performance may not be exhibited at extremely
cold locations (Where water freezes).
Specifications
Laser Section (DVD)
Wavelength .................................................................. 643 ~ 683 nm
Laser power class ............................................................ class 2 (IEC)
General Section
Power consumption ................................................................. 40 W
Dimensions ............................................... W : 440 mm (17-5/16”)
H : 127 mm (5”)
D : 410 mm (16-1/8”)
Weight (net) ................................................................. 6.8 kg (15 lb)
For your records
Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the
space provided below. Refer to the model and serial numbers whenever you call upon your dealer for information or
service on this product.
Model Serial Number
