English | 47

Output signals through the DIGITAL OUT terminal

Output signals are different depending on the “DIGITAL AUDIO OUTPUT” setting on the setup menu (see
page 41).

Playback Disc

Output Signal

STREAM/PCM

DOLBY DIGITAL/

PCM

PCM ONLY

OFF

DVD-Video 48 kHz, 16/20/24 bits

Linear PCM

48 kHz, 16 bits stereo Linear PCM *

OFF

96 kHz Linear PCM

48 kHz, 16 bits stereo Linear PCM

Dolby Digital

Dolby Digital bitstream

48 kHz, 16 bits

stereo Linear PCM

DTS

DTS bitstream

MPEG Audio

MPEG bitstream

48 kHz, 16 bits stereo Linear PCM

Audio CD, Video CD

44.1 kHz, 16 bits stereo Linear PCM /

48 kHz, 16 bits stereo Linear PCM

Audio CD with DTS

DTS bitstream

DivX/
MPEG

Dolby Digital

Dolby Digital bitstream

48 kHz, 16 bits

stereo Linear PCM

MPEG Audio

32/44.1/48 kHz, 16 bits Linear PCM

MP3/WMA

32/44.1/48 kHz, 16 bits Linear PCM

WAV

44.1 kHz, 16 bits stereo Linear PCM

* Digital signals may be emitted at 20 or 24 bits (at their original bit rate) through the DIGITAL OUT terminal if the

discs are not copy-protected.

Adjustable sound elements

Sound elements

Range/selectable items

Band 1

(100 Hz)

Band 2

(320 Hz)

Band 3
(1 kHz)

Band 4

(3.2 kHz)

Band 5

(10 kHz)

Frequency

68 Hz
100 Hz
150 Hz

210 Hz
320 kHz
460 kHz

680 Hz
1 kHz
1.5 kHz

2.1 kHz
3.2 kHz
4.6 kHz

6.8 kHz
10 kHz
15 kHz

Level

–6 to +6

Q (Q-slope)

Q0.7
Q1.0
Q1.4
Q2.0

Continued on the next page
