6
|
KDC-MP238/CR/KDC-MP208/KDC-138/CR
General Operation
Audio Control
1
Select the source to adjust
Press the [SRC] button.
2
Enter Audio Control mode
Press the [VOL] knob.
3
Select the Audio item to adjust
Press the [VOL] knob.
Adjustment Item Display
Range
Subwoofer level*
“SW L”/ “L SUB”
–15 — +15
System Q
“NATURAL/FLAT”/
“ROCK”/ “POPS”/
“EASY”/ “TOP40/TP40”/
“JAZZ”/ “USER”
Natural/Rock/Pops/Easy/
Top 40/Jazz/User setting
Bass level
“BAS L”/ “L BAS”
–8 — +8
Middle level
“MID L”/ “L MID”
–8 — +8
Treble level
“TRE L”/ “L TRE”
–8 — +8
Balance
“BAL”/ “BL”
Left 15 — Right 15
Fader
“FAD”/ “FD”
Rear 15 — Front 15
Exit Audio Control mode (Volume control mode)
*Function of KDC-MP238/MP238CR/MP208/138.
⁄
• “USER”: This appears when Bass level, Middle level, and
Treble level are adjusted. When “USER” is selected,
these levels are recalled.
4
Adjust the Audio item
Turn the [VOL] knob.
5
Exit Audio Control mode
Press any button.
Press a button other than the [VOL] knob.
Audio Setup
Setting the Sound system.
1
Select the source to adjust
Press the [SRC] button.
2
Enter Audio Setup mode
Press the [VOL] knob for at least 1 second.
3
Select the Audio Setup item to adjust
Press the [VOL] knob.
Adjustment Item Display
Range
Low Pass Filter*
“LPF”
80/120/160/Through(OFF) Hz
Volume offset
“V-OFF”/ “V-OF” –8 — ±0 (AUX: -8 — +8)
*Function of KDC-MP238/MP238CR/MP208/138.
⁄
• Volume offset: Sets each source’s volume as a difference
from the basic volume.
4
Adjust the Audio setup item
Turn the [VOL] knob.
5
Exit Audio Setup mode
Press the [VOL] knob for at least 1 second.
Speaker Setting
Fine-tuning so that the System Q value is optimal
when setting the speaker type.
1
Enter Standby
Press the [SRC] button.
Select the “STANDBY”/ “STBy” display.
2
Enter Speaker Setting mode
Press the [VOL] knob.
3
Select the Speaker type
Turn the [VOL] knob.
Speaker type
Display
OFF
“SP OFF”/ “SP-F”
For 5 & 4 in. speaker
“SP 5/4”/ “SP-5”
For 6 & 6x9 in. speaker
“SP 6*9/6”/ “SP-6”
For the OEM speaker
“SP OEM”/ “SP-O”
4
Exit Speaker Setting mode
Press the [VOL] knob.
Function of KDC-MP238/KDC-MP238CR/KDC-MP208
Switching Display
Changing the information displayed.
1
Enter Switching Display mode
Press the center of the Control knob for at least
1 second.
“DISP SEL” is displayed.
2
Select the Display item
Press the right or left side of the Control knob.
In Tuner source
Information
Display
Frequency
“FREQ”
Clock
“CLOCK”
