Kodak INTRAORAL 1500 - Manual (Page 3)

KODAK 1500 Intraoral Camera User’s Guide (8G7939) iii
Contents
About This Guide
Chapter 1
KODAK 1500
Intraoral Camera
Overview
Camera Components . . . . . . . 1
Wireless Camera . . . . . . . . 1
Wired Camera . . . . . . . . . 3
Camera Holder Components . . . 4
Docking Station Components . . . 4
Charge Station Components . . . 7
System Components . . . . . . . 8
Chapter 2
Acquisition Module
Overview
Computer System Requirements . .11
General Software Overview . . . .11
KODAK Dental Imaging
Software . . . . . . . . . . . .11
KODAK Acquisition Module . . .12
Capture Window . . . . . .12
Settings . . . . . . . . . .13
Review Window . . . . . . .14
Image Processing Toolbar . .15
Chapter 3
Getting Started
Setting Up the KODAK 1500 Intraoral
Camera . . . . . . . . . . . . . .17
Inserting the Battery into a
Wireless Camera . . . . . . . .17
Inserting the Cable into a
Wired Camera . . . . . . . . .18
Setting up the Camera Holder . . .18
Setting up the Docking Station . .20
Connecting the Docking
Station to a Computer . . . . .20
Connecting the Docking
Station to a Video Monitor. . . .21
Status Icons . . . . . . . . . .23
Setting up the Charge Station
for a Wireless Camera . . . . . . .26
Connecting the Charge Station
to the Docking Station . . . . .27
Connecting the Antenna to the
Docking Station . . . . . . . .28
