This catalog covers: GRID NO. This grid covers:
’08 KX450D8F Chassis F-3 Front Master Cylinder
Quantity-KX450
’08
Ref.
No.
Part No. Description Spec Code
D8F
13236 13236-1346 LEVER-COMP,FRONT BRAKE 1
43015 43015-1674 CYLINDER-ASSY-MASTER,FR 1
43020 43020-1123 PISTON-COMP-BRAKE 1
43022 43022-1010 STOPPER-BRAKE,PISTON 1
43026 43026-1075 CAP-BRAKE 1
43028 43028-1067 DIAPHRAGM 1
43034 43034-1110 HOLDER-BRAKE 1
43095 43095-0286 HOSE-BRAKE,FR 1
49006 49006-1344 BOOT,FRONT BRAKE LEVER 1
49016 49016-1044 COVER-SEAL,MASTER CYLINDER 1
49091 49091-0001 WASHER-SEAL,10.1X14.5X1.5 4
92009 92009-1458 SCREW,4MM 2
92015 92015-1528 NUT,FLANGED,6MM 1
92022 92022-1814 WASHER 1
92150 92150-1451 BOLT,LEVER SET 1
92150A 92150-1452 BOLT 2
92153 92153-0627 BOLT,OIL,L=23 2
92153A 92153-0695 BOLT,6X16 2
92171 92171-0481 CLAMP,BRAKE HOSE,LH 1
92171A 92171-0482 CLAMP,BRAKE HOSE,RH 1
40 MAY 29,2007
