Kawasaki MICRO-K KX450 D8F - Manual (Page 26)

This catalog covers: GRID NO. This grid covers:
’08 KX450D8F Engine B-10 Camshaft(s)/Tensioner
Quantity-KX450
’08
Ref.
No.
Part No. Description Spec Code
D8F
11061 11061-0260 GASKET 1
12046 12046-0043 SPROCKET,34T 1
12048 12048-0021 TENSIONER-ASSY 1
12053 12053-0031 GUIDE-CHAIN,CAM CHAIN STOPPER 1
12053A 12053-0051 GUIDE-CHAIN,UPP 1
12053B 12053-0064 GUIDE-CHAIN,FR 1
12053C 12053-0065 GUIDE-CHAIN,RR 1
13042 13042-0005 WEIGHT 2
14013 14013-0001 RING-POSITION 2
49118 49118-0087 CAMSHAFT-COMP,INTAKE 1
49118A 49118-0088 CAMSHAFT-COMP,EXHAUST 1
92057 92057-0035 CHAIN,98XRH2010-124M 1
92145 92145-0390 SPRING 1
92150 92150-1650 BOLT,SOCKET,6X10 2
92151 92151-1930 BOLT,FLANGED-SMALL,6X25 2
92153 92153-0717 BOLT,8X29.5 1
92153A 92153-1380 BOLT,6X6 1
482 482J5000 CIRCLIP-TYPE-E 2
670 670D2010 O RING 1
8 MAY 29,2007
