This catalog covers: GRID NO. This grid covers:
’08 KX450D8F Engine B-12 Kickstarter Mechanism
Quantity-KX450
’08
Ref.
No.
Part No. Description Spec Code
D8F
13061 13061-0146 BOSS 1
13064 13064-0051 LEVER-ASSY-KICK 1
13066 13066-0008 SHAFT-KICK 1
13070 13070-1378 GUIDE,KICK SPRING 1
13078 13078-0008 RATCHET 1
13206 13206-0005 GUIDE-KICK 1
59051 59051-0030 GEAR-SPUR,30T 1
59051A 59051-0046 GEAR-SPUR,33T 1
92022 92022-1885 WASHER,20.3X28.0X0.5 1
92022A 92022-1944 WASHER,10X22X3.2 1
92022B 92022-271 WASHER,18.3X22X0.5 1
92049 92049-1387 SEAL-OIL,KICK PEDAL 1
92081 92081-020 SPRING,KICK PEDAL 1
92145 92145-0162 SPRING 1
92145A 92145-0297 SPRING,RETURN 1
92150 92150-1858 BOLT,8X25 1
92172 92172-1088 SCREW,6X30 1
92200 92200-0075 WASHER,18.3X24X0.5 1
132 132BA0616 BOLT-FLANGED-SMALL,6X16 1
290 290CA0808 SCREW-SET-SOCKET,8X8 1
480 480J1800 CIRCLIP-TYPE-C,18MM 2
480A 480J1900 CIRCLIP-TYPE-C,19MM 2
600 600A0800 BALL-STEEL,1/4" 1
10 MAY 29,2007
