Kawasaki MICRO-K KX450 D8F - Manual (Page 30)

This catalog covers: GRID NO. This grid covers:
’08 KX450D8F Engine B-14 Transmission
Quantity-KX450
’08
Ref.
No.
Part No. Description Spec Code
D8F
13127 13127-0046 SHAFT-TRANSMISSION INPUT,16T 1
13128 13128-0033 SHAFT-TRANSMISSION OUTPUT 1
13144 13144-0017 SPROCKET-OUTPUT,13T 1
13262 13262-0390 GEAR,INPUT 2ND,17T 1
13262A 13262-0391 GEAR,INPUT 3RD,16T 1
13262B 13262-0392 GEAR,INPUT 4TH,19T 1
13262C 13262-0393 GEAR,INPUT 5TH,24T 1
13262D 13262-0394 GEAR,OUTPUT LOW,28T 1
13262E 13262-0395 GEAR,OUTPUT 2ND,24T 1
13262F 13262-0396 GEAR,OUTPUT 3RD,19T 1
13262G 13262-0397 GEAR,OUTPUT 4TH,19T 1
13262H 13262-0398 GEAR,OUTPUT 5TH,21T 1
92015 92015-1963 NUT,20MM 1
92028 92028-1857 BUSHING,INPUT TOP GEAR 1
92033 92033-1172 RING-SNAP,25MM 4
92055 92055-1293 RING-O,21.5X1.5 1
92152 92152-0150 COLLAR,25X30X13.2 1
92152A 92152-0540 COLLAR 1
92200 92200-1065 WASHER 1
92200A 92200-1389 WASHER 2
12 MAY 29,2007
