Names of parts – Konica Minolta DiMAGE Z1 User Manual
Page 10
10
N
AMES OF PARTS
* This camera is a sophisticated optical instrument. Care should be taken to keep these surfaces
clean. Please read the care and storage instructions in the back of this manual (p. 109).
Names of parts
Shutter-release button
Lens*
Self-timer lamp (p. 47)
Flash (p. 26)
Strap eyelet (p.
12
)
The USB port and AV-out terminal are located behind the card-slot door. The battery-chamber door
(p. 13) and tripod socket are located on the bottom of the body.
Speaker
Microphone
Card-slot door (p.
16)
Diopter-adjustment
dial (p. 17)
AF window*
