Krell Home Theater Standard 7.1 Developer’s Reference
RC-5 Commands for the
Home Theater Standard 7.1
The following codes are used for controlling the Home Theater
Standard 7.1 via IR.
SYSTEM
COMMAND
SYSTEM
COMMAND RC5 WORD HOME THEATER
(HEX)
(HEX)
(DEC)
(DEC)
(HEX)
STANDARD 7.1
1C
1
28
1
3701
SUB
1C
2
28
2
3702
REAR
1C
6
28
6
3706
CENTER
1C
7
28
7
3707
MUTE
1C
B
28
11
370B
DOWN
1C
C
28
12
370C
MENU
1C
D
28
13
370D
RIGHT
1C
E
28
14
370E
ENTER
1C
F
28
15
370F
LEFT
1C
10
28
16
3710
TAPE
1C
11
28
17
3711
UP
1C
12
28
18
3712
PREV
1C
19
28
25
3719
7.1 INPUT
1C
1A
28
26
371A
BALANCE
1C
1B
28
27
371B
B1
1C
1C
28
28
371C
S1
1C
1D
28
29
371D
S2
1C
1E
28
30
371E
S3
1C
1F
28
31
371F
S4
1C
20
28
32
3720
S5
1C
21
28
33
3721
COAX1
1C
22
28
34
3722
COAX2
1C
23
28
35
3723
OPT1
1C
24
28
36
3724
OPT2
1C
27
28
39
3727
TAPE ON
1C
28
28
40
3728
TAPE OFF
1C
29
28
41
3729
S-VIDEO1
1C
2A
28
42
372A
S-VIDEO2
1C
2B
28
43
372B
S-VIDEO3
1C
2C
28
44
372C
S-VIDEO4
1C
2D
28
45
372D
COMPOSITE1
1C
2E
28
46
372E
COMPOSITE2
1C
2F
28
47
372F
COMPOSITE3
1C
30
28
48
3730
COMPOSITE4
1C
33
28
51
3733
MUSIC1
1C
35
28
53
3735
STEREO
1C
37
28
55
3737
VOL ZERO
1C
38
28
56
3738
PWR ON
1C
39
28
57
3739
PWR OFF
1C
3A
28
58
373A
MUTE ON
1C
3B
28
59
373B
MUTE OFF
1C
3C
28
60
373C
VOL +10
1C
3D
28
61
373D
VOL -10
1C
3E
28
62
373E
PROLOGIC
19
0
25
0
3640
MUSIC2
19
1
25
1
3641
DVD
19
2
25
2
3642
LD
19
3
25
3
3643
SAT
19
4
25
4
3644
VCR
