Krell Home Theater Standard 7.1 Developer’s Reference
17
RS-232 Status Block Descriptions,
continued
Word 17: Sub Trim
Bit
Description
Bits 4 – 0: Sub Trim
Trim Settings
0 -10 dB
7
-3 dB
14
+4 dB
1
-9 dB
8
-2 dB
15
+5 dB
2
-8 dB
9
-1 dB
16
+6 dB
3
-7 dB
10
0 dB
17
+7 dB
4
-6 dB
11 +1 dB
18
+8 dB
5
-5 dB
12 +2 dB
19
+9 dB
6
-4 dB
13 +3 dB
20 +10 dB
Word 18: End of Message
Bit
Description
Bit 7 – 0:
Hexadecimal 55
7
6
5
4
3
2
1
0
Reserved
Reserved
Reserved
ST 4
ST 3
ST 2
ST 1
ST 0
7
6
5
4
3
2
1
0
0
1
0
1
0
1
0
1
