Page 15
Krell Home Theater Standard 7.1 Developer’s Reference
15
RS-232 Status Block Descriptions,
continued
Word 12: Main Zone Balance/Compression Mode
Bit
Description
Bits 4 - 0:
Balance Setting 0 – 26
Bits 5 – 6:
Compression Mode
Balance Settings
0
Right Off
9
Left +2.0
18
Right +2.5
1
Left +6
10
Left
+1.5
19
Right
+3.0
2
Left +5.5
11
Left +1.0
20 Right +3.5
3
Left +5.0
12
Left +0.5
21 Right +4.0
4
Left +4.5
13
Centered 0
22 Right +4.5
5
Left +4.0
14
Right +0.5
23 Right
+5.0
6
Left +3.5
15
Right +1.0
24 Right
+5.5
7
Left +3.0
16
Right
+1.5
25 Right
+6.0
8
Left +2.5
17
Right +2.0
26 Left
Off
Compression Modes
1
Max
2
Normal
3
Night
Word 13: Room EQ/Zone 2 Balance
Bit
Description
Bits 7 – 5: Room EQ Setting
Room EQ Setting
0
Room EQ OFF
1 Room EQ Memory 1
2 Room EQ Memory 2
3 Room EQ Memory 3
4 Room EQ Memory 4
Bits 4 - 0:
Balance Setting 0 – 26
Balance Settings
0
Right Off
9
Left +2.0
18
Right +2.5
1
Left +6
10
Left
+1.5
19
Right
+3.0
2
Left +5.5
11
Left +1.0
20 Right +3.5
3
Left +5.0
12
Left +0.5
21 Right +4.0
4
Left +4.5
13
Centered 0
22 Right +4.5
5
Left +4.0
14
Right +0.5
23 Right
+5.0
6
Left +3.5
15
Right +1.0
24 Right
+5.5
7
Left +3.0
16
Right
+1.5
25 Right
+6.0
8
Left +2.5
17
Right +2.0
26 Left
Off
7
6
5
4
3
2
1
0
Reserved
CMode 1
CMode 0
BAL 4
BAL 3
BAL 2
BAL 1
BAL 0
7
6
5
4
3
2
1
0
Room EQ 2
Room EQ 1
Room EQ 0
BAL 4
BAL 3
BAL 2
BAL 1
BAL 0
