RS-232 Status Block Descriptions,
continued
Word 3: General Status II
Bit
Description
Bit 7:
Menu mode
1 = Menu mode is active
Bit 6:
Auto Status
1 = Auto status enabled
Bit 5:
PLL Locked
1 = PLL is locked (valid digital input signal detected)
Bit 4:
Trigger 4 On
1 = Trigger 4 is on
Bit 3:
Trigger 3 On
1 = Trigger 3 is on
Bit 2:
Trigger 2 On
1 = Trigger 2 is on
Bit 1:
Trigger 1 On
1 = Trigger 1 is on
Bit 0:
DSP Running 1 = DSPs are not reset
Word 4: Current Device
Bit
Description
Bits 7 – 4: Zone 2 Current Device
Bits 3 – 0: Main Zone Current Device
Devices
0
DVD
5
CD
1
LD
6
TUNER
2
SAT
7
AUX 1
3
VCR
8
AUX 2
4
TV
9
TAPE
Word 5: Volume
Bit
Description
Bit 7 – 0:
Current Volume setting 0 – 152
Word 6: Zone 2 Volume
Bit
Description
Bit 7 – 0:
Current Zone 2 Volume setting 0 – 152
Word 7: Video Input
Bit
Description
Bit 7 – 0:
Current Video Input
Video Inputs
1
S-Video 1
7
Reserved
2
S-Video 2
8
Composite Video 1
3
S-Video 3
9
Composite Video 2
4
S-Video 4
10
Composite Video 3
5
Component Video 1
11
Composite Video 4
6
Component Video 2
12
Krell Home Theater Standard 7.1 Developer’s Reference
7
6
5
4
3
2
1
0
Menu Mode
Auto Status
PLL Locked
Trigger 4 On
Trigger 3 On
Trigger 2 On
Trigger 1 On
DSP Running
Enabled
7
6
5
4
3
2
1
0
Z2 CD3
Z2 CD2
Z2 CD1
Z2 CD0
MN CD3
MN CD2
MN CD1
MN CD0
7
6
5
4
3
2
1
0
VOL 7
VOL 6
VOL 5
VOL 4
VOL 3
VOL 2
VOL 1
VOL 0
7
6
5
4
3
2
1
0
V0L 7
V0L 6
V0L 5
V0L 4
V0L 3
V0L 2
V0L 1
V0L 0
7
6
5
4
3
2
1
0
VID IN 7
VID IN 6
VID IN 5
VID IN 4
VID IN 3
VID IN 2
VID IN 1
VID IN 0
