Rs-232 status block descriptions, Continued word 14: center trim, Word 15: surround trim – Krell Industries RS-232 User Manual
Page 16: Word 16: back trim
16
Krell Home Theater Standard 7.1 Developer’s Reference
RS-232 Status Block Descriptions,
continued
Word 14: Center Trim
Bit
Description
Bits 4 – 0:
Center Trim
Trim Settings
0
-10 dB
10
0
dB
1
-9 dB
11
+1
dB
2
-8 dB
12
+2
dB
3
-7 dB
13
+3
dB
4
-6 dB
14
+4
dB
5
-5 dB
15
+5
dB
6
-4 dB
16
+6
dB
7
-3 dB
17
+7
dB
8
-2 dB
18
+8
dB
9
-1 dB
19
+9
dB
20 +10
dB
Word 15: Surround Trim
Bit
Description
Bit 7: Mode 1/2 LED Status 1 = Mode 1 LED is On, 0 = Mode 2 LED is On
Bits 4 – 0: Surround Trim
Trim Settings
0 -10 dB
7
-3 dB
14
+4 dB
1
-9 dB
8
-2 dB
15
+5 dB
2
-8 dB
9
-1 dB
16
+6 dB
3
-7 dB
10
0 dB
17
+7 dB
4
-6 dB
11 +1 dB
18
+8 dB
5
-5 dB
12 +2 dB
19
+9 dB
6
-4 dB
13 +3 dB
20 +10 dB
Word 16: Back Trim
Bit
Description
Bits 4 – 0: Back Trim
Trim Settings
0 -10 dB
7
-3 dB
14
+4 dB
1
-9 dB
8
-2 dB
15
+5 dB
2
-8 dB
9
-1 dB
16
+6 dB
3
-7 dB
10
0 dB
17
+7 dB
4
-6 dB
11 +1 dB
18
+8 dB
5
-5 dB
12 +2 dB
19
+9 dB
6
-4 dB
13 +3 dB
20 +10 dB
7
6
5
4
3
2
1
0
Reserved
Reserved
Reserved
CT 4
CT 3
CT 2
CT 1
CT 0
7
6
5
4
3
2
1
0
Reserved
Reserved
Reserved
BT 4
BT 3
BT 2
BT 1
BT 0
7
6
5
4
3
2
1
0
Mode 1/2
Reserved
Reserved
RT 4
RT 3
RT 2
RT 1
RT 0
LED Status
