Configuration Menu Overview 30
GATEWAY
Setting
192.168.1.1
If a router is used on the network, enter the IP address of the
router. Use the Up, Down, Left, and Right keys to enter the
value. When manually setting the Gateway, first set DHCP
and BOOTP to
OFF .
MAC
ADDRESS
Displays the Ethernet hardware address for this printer. (It
cannot be changed.)
HTTP
Settings
ON / OFF
HTTP can be set to ON or OFF . ON enables the Internal Web
Page inside the printer, OFF disables it.
SNMP
Settings
ON / OFF
SNMP is a scalable, distributed management suited for
managing small to large size networks. SNMP can be set to
ON or OFF .
FORCED
MODES
Settings
SPEED/DUP/NEG. : AUTO/AUTO/ON
- AUTO/FULL/ON - AUTO/HALF/ON
- 100M/AUTO/ON - 100M/FULL/ON
- 100M/FULL/OFF - 100M/HALF/ON
- 100M/HALF/OFF - 10M/AUTO/ON
- 10M/FULL/ON - 10M/FULL/OFF
- 10M/HALF/ON - 10M/HALF/OFF
SPEED
indicates the network transmission speed. Select from
a 10Base-T connection (10M), 100Base-TX connection
(100M), or automatic recognition (AUTO). If AUTO is selected,
the transmission speed is set depending on the negotiation.
Therefore, there is no setting where negotiation (NEG.) is
turned off.
DUP
indicates the communication method for bi-directional
communication. Select whether data is sent and received in
both directions simultaneously (FULL), or in one direction at a
time (HALF), or select automatic recognition (AUTO). If AUTO is
selected, the transmission speed is set depending on the
negotiation. Therefore, there is no setting where negotiation
(NEG.) is turned off.
NEG.
indicates the negotiation setting (mutually sends and
receives information such as the transmission speed and
determines the transmission setting). When set to ON, negotia-
tion is performed. When set to OFF, negotiation is not per-
formed.
