3
The following table shows the approximate battery life
(hours) relative to the transmit output power.
Note:
◆ Charge the NiCd battery pack within an ambient temperature of
between 5
° C and 40 ° C (41 ° F and 104 ° F). Charging outside this
range may not fully charge the pack.
◆ Repeatedly recharging a fully charged NiCd battery pack, or almost
fully charged pack, shortens its operating time. To resolve this
problem, use the pack until it is completely discharged. Then
recharge the pack to full capacity.
◆ If the operating time of a fully charged NiCd battery pack is much
shorter than before, the battery life is over. Replace the pack.
INSTALLING THE ANTENNA
Hold the provided antenna at its base, and screw the
antenna into the connector on the top panel of the
transceiver until it is snug.
s e i r e t t a B
d n a B F H V d n a B F H U
H L L E H L L E
d C i N 9 3 - B P 3 6 9 3 6 9
d C i N 8 3 - B P 5 . 4 7 0 1 4 7 0 1
PC
GPS GPS
PC PC
GPS
Hand strap
Belt hook
INSTALLING THE HAND STRAP/ BELT HOOK
If desired, attach the provided hand strap and/ or belt
hook.
To remove the belt hook, pull the belt hook downward
while pushing its tabs from both sides.
To lock the cable of an optional speaker microphone,
first position the cable over the left groove on the
transceiver. Then install the belt hook. Last, position the
cable over the right groove.
